Anti-glare and thermo reflective insulation, Glareshield is a 3-in-1 Insulation, vapour barrier and reflective barrier solution used as roof insulation. It comprises a cross-linked, closed-cell insulation core sandwiched by reflective foil facings, which is water-resistant and unaffected by moisture. Glareshield is compliant with AS/NZS 4859.1:2018 and CodeMark-certified for NCC compliance.
Features:
• Australian made
• 3-in-1 Insulation, vapour barrier and reflective barrier
• CodeMark-certified for NCC compliance
• NCC and AS/NZS 4859.1:2018 compliant
• Fibre-free
• Quick and easy to install
• Anti-bacterial and anti-fungal
• Rodent and insect resistant
| Feature | Specification | Benefits |
|---|---|---|
| Product Thickness | 7 mm | Fits in narrow wall or roof spaces. |
| R-value at 23ºC | R0.14 m²·K/W | Improves indoor temperature control. |
| Roll Size | 1350 mm x 22.25 m (30 m²) | Covers more area, reducing joins and waste. |
| Roll Weight | 11 kg | Lightweight and easy to handle during installation. |
| Reflectance | Reflective: 97%, Anti-Glare: 95% | Reflects radiant heat for better thermal efficiency. |
| Emittance | Reflective: 0.03, Anti-Glare: 0.05 | Minimises heat transfer for improved comfort. |
| Max Span Distance | 2.4 m without support mesh | Can be installed without additional support in many cases. |
| Water Resistance | Pass (Water Barrier) | Prevents moisture ingress, protecting the structure. |
| Vapour Barrier | < 0.020 µg/N·s (Class 2) | Reduces condensation risk inside walls or ceilings. |
| Fire Performance | Flammability Index ≤ 5 (Low) | Meets fire safety standards for building compliance. |
